ASTM A694 F42/F46/F52/F60/F65/F70 are high-strength carbon steel grades specifically developed for high-pressure transmission service. These grades are widely used in the oil, gas, petrochemical, and power generation industries where durability and resistance to mechanical stress are critical. Manufactured using controlled forging and heat treatment processes, ASTM A694 flanges ensure structural reliability and performance under extreme service conditions. These flanges are ideal for use in systems that demand superior strength, toughness, and resistance to sour gas environments.
We offer a comprehensive range of ASTM A694 high-yield carbon steel flanges including Weld Neck (WNRF), Slip-On (SORF), Blind (BLRF), Socket Weld (SWRF), Threaded, Lap Joint, and Ring Type Joint (RTJ) flanges. These flanges are manufactured in accordance with ASME B16.5, ASME B16.47 Series A/B, and MSS SP-44 standards, available in pressure classes from 150# to 2500#, and sizes ranging from ½” to 48” NB. They undergo strict quality checks including ultrasonic testing, radiographic inspection, PMI, and hydrostatic tests, with material traceability provided as per EN 10204 3.1 / 3.2 certifications.
ASTM A694 F42 to F70 flanges are engineered for high-pressure systems such as cross-country pipelines, refineries, offshore drilling rigs, and process piping. Their high tensile and yield strength make them suitable for critical applications involving elevated temperatures and pressures. The F65 and F70 variants, in particular, are favored for their exceptional yield strength in sour gas service, conforming to NACE MR0175/ISO 15156 standards. These flanges offer long service life, dimensional stability, and leak-proof performance, making them a reliable solution for demanding environments.
As an ISO 9001:2015 certified supplier, we ensure consistent quality and traceability across all ASTM A694 flanges. Our stock includes products compliant with NACE, PED, IBR, and customer-specific quality plans. With manufacturing and sourcing capabilities across India, South Korea, Japan, Germany, and the USA, we support bulk and project-based deliveries worldwide. Whether you need urgent stock supply or custom-made flanges, our global logistics network ensures on-time delivery to the USA, UAE, Saudi Arabia, Qatar, Europe, South Africa, and Southeast Asia.
ISO Certified Supplier of ASTM A694 F46/F52/F60/F65 High-Strength Flanges – ANSI B16.5, B16.47 Series A/B – WNRF, RTJ, Lap Joint, SWRF – Forged Socket Weld & Threaded Fittings – Sizes ½” NB to 48” NB – Pressure Class 150# to 2500#.
Technical Index
Industrial ASTM A694 F42 Specifications
| Material Grade | ASTM A694 F42 / F46 / F52 / F60 / F65 / F70 (High-Yield Carbon Steel – Flanges & Forged Fittings) |
|---|---|
| Available Product Types | Flanges (WNRF, SORF, Blind, Socket Weld, Threaded, RTJ) & Forged Fittings (Elbows, Tees, Reducers, Couplings, Unions, Bushings, Caps) |
| Flanges Size Range | ½” NB to 48” NB |
| Flange Pressure Class | 150#, 300#, 600#, 900#, 1500#, 2500# |
| Forged Fittings Size | ½” NB to 4” NB (Socket Weld & Threaded) |
| Fitting Pressure Class | Class 2000#, 3000#, 6000# |
| Standard Specifications | ASTM A694 / ASME SA694 |
| Manufacturing Standards | ASME B16.5 (Flanges), ASME B16.11 (Forged Fittings), MSS SP‑44 (Flanges), MSS SP‑83, MSS SP‑95 |
| Flange Types | Weld Neck, Slip‑On, Socket Weld, Threaded, Blind, Ring‑Type Joint |
| Forged Fitting Types | 90° Elbow (LR/SR), 45° Elbow, Equal Tee, Reducing Tee, Cross, Full/Half Coupling, Union, Bushing, Cap |
| Heat Treatment | Normalized, Quenched & Tempered (as per grade) |
| Mechanical Properties | Tensile Strength: 485–655 MPa (varies by grade) Yield Strength: ≥290 MPa to ≥485 MPa (grade dependent) Elongation: ≥21% |
| Testing & Certifications | ISO 9001:2015, EN 10204 3.1/3.2 MTC, Charpy Impact Test, PMI, UT, Radiography, Hydrostatic Test, NACE MR0175 |
| Surface Finish | Black Coated, Pickled, Sand Blasted, Anti-Rust Coated |
| Manufacturing Capabilities | Hot Forging, CNC Machining, Beveling, Induction Heat Treatment, Custom Fabrication |
| Raw Material Sources | India, Japan, South Korea, USA, Germany, Italy |
| Export Destinations | USA, Canada, UAE, Saudi Arabia, Qatar, Oman, Egypt, South Africa, Nigeria, Australia, Europe |
Industrial ASTM A694 F42 Carbon Steel Standards
| ANSI/ASME B16.47 Flanges | ANSI/ASME B16.36 Flanges | ANSI/ASME B16.5 Flanges | Pr. EN1902-1 Flanges |
| DIN Flanges | JIS Flanges | BS 4504 Flanges | BS 10 Flanges |
| MSS SP-44 Flanges | JIS B2220 Flanges | KS B1503 Flanges | UNI Flanges |
| SABS/SANS 1123 Flanges | AS 2129, AS 4087 Flanges | ISO 9624, ISO 7005-1 Flanges | AWWA Flanges Standard |
| GOST Standard Flanges | API Flanges | AS/ANZ 4331.1 Flanges | Series A Flange |
| Series B Flange | SAE J518 Flanges | GB Flange | Norwegian Standard Flanges |
| ASME B16.11 – Forged Steel Fittings, Socket-Welding and Threaded | BS 3799 – Screwed and Socket-Welding for the Petroleum Industry | MSS SP-79 – Socket-Welding Reducer Inserts | MSS SP-83 – Class 3000 Steel Pipe Unions, Socket-Welding and Threaded |
| MSS SP-95 – Swage(d) Nipples and Bull Plugs | MSS SP-97 – Integrally Reinforced Forged Branch Outlet Fittings | DIN 2986 – Threaded Fittings | DIN 2999 – Pipe Threads for Fittings (British Standard Pipe Threads) |
| ISO 49 – Malleable Iron Fittings, Threaded | ISO 7/1 – Pipe Threads Where Pressure-tight Joints Are Made on the Threads | EN 10241 – Steel Threaded Pipe Fittings | JIS B2316 – Japanese standard for forged pipe fittings. |
