ASME-compliant Buttweld Fittings (B16.9), Forged Fittings (B16.11), MSS-SP Outlet Fittings, and ASME B16.5 Industrial Flanges supplied across Turkey, including Istanbul, Ankara, Izmir, and Bursa.
Bhavani Industries delivers piping components into the Turkish market with an execution model built around design code compliance and fabrication-ready accuracy. Our supply scope covers ASME B16.9 buttweld fittings, ASME B16.11 forged fittings, MSS-SP outlet fittings, and ASME B16.5 flanges, selected to match line class requirements, pressure design limits, and welding configurations used in refineries, power stations, and large-scale industrial plants across Turkey.
Rather than treating fittings and flanges as standard catalog items, Bhavani Industries focuses on dimensional repeatability, bore alignment, and end-preparation quality to ensure predictable weld behavior and fit-up during fabrication. Material selection is controlled at the heat level, with chemical composition, mechanical properties, and heat treatment conditions verified against applicable ASTM and ASME specifications. This approach reduces welding defects, minimizes stress concentration points, and improves in-service reliability under thermal and pressure cycling.
To support project execution across Istanbul, Ankara, Izmir, Bursa, Kocaeli, and Adana, Bhavani Industries supplies components with complete traceability and inspection records, including EN 10204 3.1 certification, PMI mapping, dimensional inspection reports, and acceptance criteria aligned with client and third-party requirements. By aligning product supply with construction sequencing, inspection hold points, and site logistics, we help EPC contractors and fabricators in Turkey achieve consistent quality while maintaining schedule discipline on technically demanding projects.
Manufactured using certified Stainless Steel, Carbon Steel, Alloy Steel, Duplex, Super Duplex, and Nickel Alloys, our products meet ASME, ANSI, and DIN specifications, ensuring long-term reliability for critical applications throughout Turkey’s industrial and construction landscape.
Technical Index
ASME Flanges and Pipe Fittings Specifications for Turkey
| Product | Standards | Size Range | Pressure Class / Schedule | Materials |
|---|---|---|---|---|
| Buttweld Fittings | ASME B16.9, MSS-SP-43 | ½” to 48” | Sch. 10 to Sch. 160 | CS, SS, Alloy Steel, Duplex, Super Duplex, Nickel Alloys |
| Forged Fittings | ASME B16.11, MSS-SP-79/83/95 | ⅛” to 4” | 2000, 3000, 6000, 9000 | ASTM A105 CS, A182 F304/316 SS, Alloy Steel, Inconel, Monel, Hastelloy |
| Outlet Fittings | MSS-SP-97 | ⅛” to 24” | 3000#, 6000#, 9000# | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Nickel Alloys |
| Industrial Flanges | ASME B16.5, ASME B16.47, MSS-SP-44 | ½” to 60” | 150#, 300#, 600#, 900#, 1500#, 2500# | CS, SS, Alloy Steel, Duplex, Super Duplex, Copper Nickel, Titanium |
Pipe Fittings and Flanges – International Standards
| Product / Category | Applicable Standards |
|---|---|
| Forged Fittings |
ASME B16.11 – Forged Steel Fittings, Socket-Welding and Threaded BS 3799 – Screwed and Socket-Welding for the Petroleum Industry MSS SP-79 – Socket-Welding Reducer Inserts MSS SP-83 – Class 3000 Steel Pipe Unions, Socket-Welding and Threaded MSS SP-95 – Swage(d) Nipples and Bull Plugs MSS SP-97 – Integrally Reinforced Forged Branch Outlet Fittings DIN 2986 – Threaded Fittings DIN 2999 – Pipe Threads for Fittings (British Standard Pipe Threads) ISO 49 – Malleable Iron Fittings, Threaded ISO 7/1 – Pipe Threads Where Pressure-tight Joints Are Made on the Threads EN 10241 – Steel Threaded Pipe Fittings JIS B2316 – Japanese Standard for Forged Pipe Fittings |
| Buttweld Fittings |
ASME B16.9 – Factory-made Wrought Buttwelding Fittings MSS SP-43 – Wrought Buttwelding Fittings DIN 2615 – Steel Butt-welding Elbows DIN 2616 – Steel Butt-welding Tees ISO 5251 – Steel Butt-welding Fittings EN 10253 – Butt-welding Fittings for Steel Pipes |
| Outlet Fittings |
MSS SP-97 – Integrally Reinforced Forged Branch Outlet Fittings ASME B16.11 – Socket-Welding and Threaded Forged Fittings ISO 49 – Malleable Iron Threaded Fittings DIN 2986 – Threaded Fittings |
| Industrial Flanges |
ASME B16.5 – Pipe Flanges and Flanged Fittings (½”–24”) ASME B16.47 – Large Diameter Steel Flanges (NPS 26–60) MSS SP-44 – Steel Pipe Line Flanges for Water, Steam, Oil, Gas EN 1092 – Flanges and their Joints for Steel Pipes ISO 7005 – Metallic Flanges for Pipework JIS B2220 – Japanese Standard for Steel Flanges ASME B16.36 – Orifice Flanges |
Material Specifications of Pipe Fittings and Flanges in Turkey
| Material | Grades |
|---|---|
| Carbon Steel | 105, 106B, LF2, F1, F5, F9, F11, F22, F91, F92, A350 LF1, LF3 |
| Stainless Steel | 304, 304L, 316, 316L, 321, 321H, 347, 347H, 310, 410, 430, 904L |
| Alloy Steel | 5, 9, 11, 12, 22, 91, 92, 5Cr, 9Cr, 12Cr, 15Cr, F5, F9, F11, F22, F91, F92 |
| Duplex Stainless Steel | 31803, 32205, 2205, 2507 |
| Super Duplex Stainless Steel | 32750, 32760, 2507, Zeron 100 |
| Nickel Alloys | Inconel 600, 625, 718, 825, Monel 400, K500, Hastelloy C-22, C-276, Alloy 20 |
| Titanium | 2, 5, 7, 12 |
| Copper-Nickel | 70/30, 90/10 |
| Aluminium Bronze | C95400, C95500, C95800 |
| Lead Bronze | LG2, LG5, LG7 |
| Other Special Alloys | 254SMO, Nimonic 80A, Alloy 625, Alloy 825 |
Our Product Range in Turkey
Applications of Pipe Fittings and Flanges in Turkey
Export Supply of Fittings and Flanges in Turkey Cities
Samsun, Kayseri, Eskisehir, Sakarya, Tekirdag, Corlu, Denizli, Manisa, Aydin, Balikesir, Hatay, Iskenderun, Zonguldak, Karabuk, Trabzon, Rize, Malatya, Elazig, Diyarbakir, Sanliurfa
