Comprehensive Range of Alloy Steel Buttweld Fittings – ASTM A234 WP1/WP5/WP9 & A182 F1/F5/F9 Flanges & Forged Elbows – WNRF, SORF, SW, Threaded, Elbows, Tees, Reducers | ANSI, DIN, EN Standards .
Alloy steel is a premium material class engineered for high-strength and high-temperature applications. We offer a wide range of pipe fittings, flanges, and branch connections manufactured from top alloy steel grades including ASTM A182 F1, F5, F9, F11, F22, F91 and ASTM A234 WP1, WP5, WP11, WP22, WP91. These components are widely used in refineries, power plants, petrochemical, and thermal processing industries where durability under extreme conditions is critical.
Our alloy steel inventory includes buttweld pipe fittings (Elbows, Tees, Reducers, Caps, Stub Ends), forged fittings (Socket Weld & Threaded Elbows, Tees, Couplings, Plugs, Unions), flanges (WNRF, SORF, BLRF, Threaded, Lap Joint, RTJ), and branch outlet fittings like Weldolet, Sockolet, and Threadolet. All products adhere to ANSI/ASME B16.5, B16.9, B16.11, MSS SP-97, MSS SP-83, and DIN/EN specifications ensuring global compatibility.
Fittings are available in sizes from ½” NB to 48” NB. Flange pressure classes include Class 150, 300, 600, 900, 1500, and 2500, as well as PN6 to PN64. Forged fittings are supplied in pressure ratings of 2000#, 3000#, 6000#, and 9000#. Buttweld fittings are manufactured in wall thickness ranging from SCH 10 to SCH XXS and comply with ASME B36.10/36.19 dimensional standards. Our olets support branch sizes from ½” to 24” for header pipes up to 36”.
All products are manufactured as per ASTM A182 and A234 standards with strict quality control under ISO 9001:2015 systems. Heat treatment, PMI testing, hydrotesting, ultrasonic inspection, and third-party inspection are standard practices. With material sourcing from reputed mills in Europe, Japan, and India, we ensure full traceability and documentation including EN 10204 3.1/3.2 certificates. Our alloy steel range is extensively used in high-pressure steam lines, boiler systems, power generation, and oil & gas pipelines.
Global Supplier of Alloy Steel Fittings & Flanges – Buttweld (Elbows, Tees, Reducers, Caps, Stub Ends), Forged SW/Threaded Fittings (Elbows, Tees, Couplings, Unions, Plugs) – Flange Types: WNRF, SORF, BLRF, SWRF, RTJ, Lap Joint – Sizes ½” to 48” – ASME B16.9, B16.11, B16.5, B16.47, MSS SP-75 – Class 150 to 2500, SCH 10 to XXS – ISO Certified Export Quality
Technical Index
Industrial Alloy Steel Specifications
| Material Grade | ASTM A182 F1, F5, F9, F11, F22, F91 (Forged Fittings, Flanges), ASTM A234 WP1, WP5, WP9, WP11, WP22, WP91 (Buttweld Fittings) |
|---|---|
| Available Product Types | Flanges (WNRF, SORF, Blind, Socket Weld, Threaded, RTJ) & Forged Fittings (Elbows, Tees, Reducers, Couplings, Unions, Bushings, Caps) |
| Flanges Size Range | ½” NB to 24” NB |
| Flange Pressure Class | 150#, 300#, 600#, 900#, 1500#, 2500# |
| Forged Fittings Size | ½” NB to 4” NB (Socket Weld & Threaded) |
| Fitting Pressure Class | Class 2000#, 3000#, 6000# |
| Standard Specifications | ASTM A182 / ASME SA182 |
| Manufacturing Standards | ASME B16.5 (Flanges), ASME B16.11 (Forged Fittings), MSS SP‑83, MSS SP‑44 (Flanges), MSS SP‑95 |
| Flange Types | Weld Neck, Slip‑On, Socket Weld, Threaded, Blind, Ring‑Type Joint |
| Forged Fitting Types | 90° Elbow (LR/SR), 45° Elbow, Equal Tee, Reducing Tee, Cross, Full/Half Coupling, Union, Bushing, Cap |
| Size Range | ½” NB to 24” NB (Seamless), ½” NB to 48” NB (Welded) |
| Wall Thickness | SCH 10, SCH 20, SCH 40, SCH 80, SCH 120, SCH 160, XXS |
| Standard Specifications | ASTM A234 / ASME SA234, ANSI B36.10, B36.19 |
| Manufacturing Standards | ASME B16.9, MSS SP-75, EN 10253, DIN 2605/2615/2616, ISO 3419, JIS B2312 |
| Types | 90° Elbow (LR/SR), 45° Elbow, Equal Tee, Reducing Tee, Concentric Reducer, Eccentric Reducer, End Cap, Stub End |
| Form | Seamless, Welded, Fabricated |
| Heat Treatment | Normalized, Tempered, Quenched & Tempered (per grade) |
| Mechanical Properties | Tensile Strength: 380–620 MPa (varies by grade) Yield Strength: 205–415 MPa (varies by grade) Elongation: ≥20% |
| Testing & Certifications | ISO 9001:2015, EN 10204 3.1/3.2 MTC, PMI, UT, Radiography, Hydrostatic Test, NACE MR0175 |
| Surface Finish | Pickled, Passivated, Sand Blasted, Black Coated |
| Manufacturing Capabilities | Hot Forging, CNC Machining, Beveling, Induction Heat Treatment, Custom Fabrication |
| Raw Material Sources | India, Japan, South Korea, USA, Germany, Italy |
| Export Destinations | USA, Canada, UAE, Saudi Arabia, Qatar, Oman, Egypt, South Africa, Nigeria, Australia, Europe |
Industrial Alloy Steel Standards
| ANSI/ASME B16.47 Flanges | ANSI/ASME B16.36 Flanges | ANSI/ASME B16.5 Flanges | Pr. EN1902-1 Flanges |
| DIN Flanges | JIS Flanges | BS 4504 Flanges | BS 10 Flanges |
| MSS SP-44 Flanges | JIS B2220 Flanges | KS B1503 Flanges | UNI Flanges |
| SABS/SANS 1123 Flanges | AS 2129, AS 4087 Flanges | ISO 9624, ISO 7005-1 Flanges | AWWA Flanges Standard |
| GOST Standard Flanges | API Flanges | AS/ANZ 4331.1 Flanges | Series A Flange |
| Series B Flange | SAE J518 Flanges | GB Flange | Norwegian Standard Flanges |
| ASME B16.11 – Forged Steel Fittings, Socket-Welding and Threaded | BS 3799 – Screwed and Socket-Welding for the Petroleum Industry | MSS SP-79 – Socket-Welding Reducer Inserts | MSS SP-83 – Class 3000 Steel Pipe Unions, Socket-Welding and Threaded |
| MSS SP-95 – Swage(d) Nipples and Bull Plugs | MSS SP-97 – Integrally Reinforced Forged Branch Outlet Fittings | DIN 2986 – Threaded Fittings | DIN 2999 – Pipe Threads for Fittings (British Standard Pipe Threads) |
| ISO 49 – Malleable Iron Fittings, Threaded | ISO 7/1 – Pipe Threads Where Pressure-tight Joints Are Made on the Threads | EN 10241 – Steel Threaded Pipe Fittings | JIS B2316 – Japanese standard for forged pipe fittings. |
| ANSI/ASME B16.9 – Factory-Made Wrought Steel Buttwelding Fittings | ANSI/ASME B16.28 – Wrought Steel Short Radius Elbows and Returns | ANSI/ASME B16.25 – Buttwelding Ends(beval standards) | MSS SP-43 – Wrought and fabricated Butt welding Fittings for Light Wall Applications |
| MSS SP-75 – High Test Wrought Butt welding Fittings | DIN 2616 – Butt welding Pipe Fittings: Reducers | DIN 2617 – Butt welding Pipe Fittings: Caps | DIN28011 – Dished Ends(used in pressure vessels) |
| EN10253-1 Butt-welding Pipe Fittings(Non Alloy Steels) | EN10253-2 Butt-welding Pipe Fittings(Stainless/Alloy Steels) |
Alloy Steel International Standards
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| ASTM A182 F1 | 1.5415 | K12822 | STPA 20 | 3604 | 12Х1МФ | 15CD2.05 | 16Mo3 |
| ASTM A182 F5 | 1.7362 | K41545 | STPA 25 | 622-490 | 15Х5М | 15CD5.05 | 13CrMo44 |
| ASTM A182 F9 | 1.7380 | K90941 | STPA 23 | 622-490 | 15Х9М | 15CD9.05 | 10CrMo9-10 |
| ASTM A182 F11 | 1.7335 | K11597 | STPA 22 | 621-550 | 12Х1МФ | 15CD2.05 | 13CrMo4-5 |
| ASTM A182 F22 | 1.7383 | K21590 | STPA 24 | 621-570 | 12Х2М | 15CD2.25 | 10CrMo9-10 |
| ASTM A182 F91 | 1.4903 | K90901 | STPA 28 | 620-590 | — | Z15CDNbV12.1 | X10CrMoVNb9-1 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| ASTM A234 WP1 | 1.5415 | K11522 | STPA 20 | 3604 | 12Х1МФ | 15CD2.05 | 16Mo3 |
| ASTM A234 WP5 | 1.7362 | K41545 | STPA 25 | 622-490 | 15Х5М | 15CD5.05 | 13CrMo44 |
| ASTM A234 WP9 | 1.7380 | K90941 | STPA 23 | 622-490 | 15Х9М | 15CD9.05 | 10CrMo9-10 |
| ASTM A234 WP11 | 1.7335 | K11597 | STPA 22 | 621-550 | 12Х1МФ | 15CD2.05 | 13CrMo4-5 |
| ASTM A234 WP22 | 1.7383 | K21590 | STPA 24 | 621-570 | 12Х2М | 15CD2.25 | 10CrMo9-10 |
| ASTM A234 WP91 | 1.4903 | K90901 | STPA 28 | 620-590 | — | Z15CDNbV12.1 | X10CrMoVNb9-1 |
Alloy Steel Chemical Composition
| Grade | C (%) | Mn (%) | Si (%) | Cr (%) | Mo (%) | P (%) | S (%) | Other Elements |
|---|---|---|---|---|---|---|---|---|
| ASTM A182 F1 | 0.10–0.20 | 0.30–0.80 | 0.10–0.50 | 0.50–0.80 | 0.44–0.65 | ≤0.035 | ≤0.040 | — |
| ASTM A182 F5 | ≤0.15 | 0.30–0.60 | 0.50–1.00 | 4.00–6.00 | 0.45–0.65 | ≤0.030 | ≤0.030 | — |
| ASTM A182 F9 | ≤0.15 | 0.30–0.60 | 0.50–1.00 | 8.00–10.00 | 0.90–1.10 | ≤0.030 | ≤0.030 | — |
| ASTM A182 F11 | 0.05–0.15 | 0.30–0.60 | 0.50–1.00 | 1.00–1.50 | 0.44–0.65 | ≤0.030 | ≤0.030 | — |
| ASTM A182 F22 | 0.05–0.15 | 0.30–0.60 | 0.50–1.00 | 1.90–2.60 | 0.87–1.13 | ≤0.030 | ≤0.030 | — |
| ASTM A182 F91 | 0.08–0.12 | 0.30–0.60 | 0.20–0.50 | 8.00–9.50 | 0.85–1.05 | ≤0.020 | ≤0.010 | V: 0.18–0.25, Nb: 0.06–0.10, N: 0.03–0.07 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Other Elements |
| ASTM A234 WP1 | 0.10–0.20 | 0.30–0.80 | 0.10–0.50 | ≤ 0.035 | ≤ 0.040 | 0.50–0.80 | 0.40–0.65 | — |
| ASTM A234 WP5 | ≤ 0.15 | 0.30–0.60 | 0.50 max | ≤ 0.030 | ≤ 0.030 | 4.00–6.00 | 0.45–0.65 | — |
| ASTM A234 WP9 | ≤ 0.15 | 0.30–0.60 | 0.25–1.00 | ≤ 0.030 | ≤ 0.030 | 8.00–10.00 | 0.90–1.10 | — |
| ASTM A234 WP11 | 0.05–0.15 | 0.30–0.60 | 0.50–1.00 | ≤ 0.030 | ≤ 0.030 | 1.00–1.50 | 0.44–0.65 | — |
| ASTM A234 WP22 | 0.05–0.15 | 0.30–0.60 | 0.50 max | ≤ 0.025 | ≤ 0.025 | 1.90–2.60 | 0.87–1.13 | — |
| ASTM A234 WP91 | 0.08–0.12 | 0.30–0.60 | 0.20–0.50 | ≤ 0.020 | ≤ 0.010 | 8.00–9.50 | 0.85–1.05 | V: 0.18–0.25, Nb: 0.06–0.10, N: 0.03–0.07 |
Alloy Steel Mechanical Properties
| Grade | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (%) | Hardness (HBW) | Impact Energy (J) |
|---|---|---|---|---|---|
| ASTM A182 F1 | 380 min | 205 min | 22 min | ≤197 | 27 (typical) |
| ASTM A182 F5 | 415 min | 205 min | 20 min | ≤207 | 27 (typical) |
| ASTM A182 F9 | 585 min | 275 min | 20 min | ≤217 | 27 (typical) |
| ASTM A182 F11 | 415 min | 205 min | 20 min | ≤197 | 27 (typical) |
| ASTM A182 F22 | 415–585 | 205–415 | 18–22 | ≤235 | 27 (typical) |
| ASTM A182 F91 | 585–760 | 415 min | 20 min | ≤250 | ≥41 (Charpy V-notch @ RT) |
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HBW) | Temperature Range (°C) |
| ASTM A234 WP1 | 380 min | 205 min | 22 min | 163 max | -29 to 427 |
| ASTM A234 WP5 | 415 min | 205 min | 22 min | 163 max | Up to 593 |
| ASTM A234 WP9 | 585 min | 275 min | 20 min | 190 max | Up to 593 |
| ASTM A234 WP11 | 485 min | 275 min | 20 min | 187 max | Up to 593 |
| ASTM A234 WP22 | 620 min | 415 min | 20 min | 190 max | Up to 650 |
| ASTM A234 WP91 | 620 min | 415 min | 20 min | 250 max | Up to 650 |
Alloy Steel Types
ASTM A182 Chrome Moly Industries & Applications
ASTM A182 Alloy Steel Flange Weight Chart
| Size | OD | WT | SR 90 Deg Elbows Centre – Face A | Weight | LR 90 Deg Elbows Centre – Face A | Weight | SR 45 Deg Elbows Centre – Face B | Weight | ||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch. | mm | mm | SCH | mm | kg | mm | kg | mm | kg |
| 500 | 20″ | 508 | 9.52 | STD | 508 | 93.5 | 762 | 140 | 318 | 85 |
| 12.7 | X.S | 508 | 124 | 762 | 186 | 318 | 112.5 | |||
| 450 | 18″ | 457 | 9.52 | STD | 457 | 75.6 | 686 | 113 | 286 | 56.5 |
| 12.7 | X.S | 457 | 100 | 686 | 150 | 286 | 75 | |||
| 400 | 16″ | 406.4 | 9.52 | STD | 406 | 59.5 | 610 | 89.3 | 254 | 45 |
| 12.7 | X.S | 406 | 78.7 | 610 | 118 | 254 | 59 | |||
| 350 | 14″ | 355.6 | 9.52 | STD | 356 | 45.4 | 533 | 68.1 | 222 | 34.1 |
| 12.7 | X.S | 356 | 60 | 533 | 90 | 222 | 45 | |||
| 300 | 12″ | 323.9 | 9.52 | STD | 305 | 35.4 | 457 | 53.1 | 190 | 26.6 |
| 12.7 | X.S | 305 | 46.7 | 457 | 70 | 190 | 35 | |||
| 250 | 10″ | 273.9 | 9.27 | STD | 254 | 24.1 | 381 | 36.1 | 159 | 18.1 |
| 12.7 | X.S | 254 | 32.5 | 381 | 48.8 | 159 | 24.4 | |||
| 200 | 8″ | 219.1 | 8.18 | STD | 203 | 13.6 | 305 | 20.4 | 127 | 10.2 |
| 12.7 | X.S | 203 | 20.9 | 305 | 30.9 | 127 | 15.5 | |||
| 150 | 6″ | 168.3 | 7.11 | STD | 152.4 | 6.8 | 229 | 10.1 | 95.2 | 5.1 |
| 10.97 | X.S | 152.4 | 10.2 | 229 | 15.3 | 95.2 | 7.7 | |||
| 125 | 5″ | 141.3 | 6.65 | STD | 127 | 4.8 | 190 | 6.8 | 79.4 | 3.4 |
| 9.5 | X.S | 127 | 6.5 | 190 | 10 | 79.4 | 5 | |||
| 100 | 4″ | 114.3 | 62 | STD | 101.6 | 2.8 | 152.4 | 4.2 | 63.5 | 2.1 |
| 8.56 | X.S | 101.6 | 3.9 | 152.4 | 5.7 | 63.5 | 2.9 | |||
| 80 | 3″ | 88.9 | 5.49 | STD | 76.2 | 1.45 | 114.3 | 2.18 | 50.8 | 1.1 |
| 7.62 | X.S | 76.2 | 1.95 | 114.3 | 2.86 | 50.8 | 1.45 | |||
| 65 | 21/2″ | 73 | 5.16 | STD | 63.5 | 0.95 | 95.2 | 1.46 | 44.4 | 0.73 |
| 71 | X.S | 63.5 | 1.27 | 95.2 | 1.82 | 44.4 | 0.91 | |||
| 50 | 2″ | 60.3 | 3.91 | STD | 50.8 | 0.5 | 76.2 | 0.72 | 34.9 | 0.36 |
| 5.54 | X.S | 50.8 | 0.68 | 76.2 | 1 | 34.9 | 0.5 | |||
| 40 | 11/2″ | 48.3 | 3.68 | STD | 38.1 | 0.26 | 57.1 | 0.4 | 28.6 | 0.2 |
| 58 | X.S | 38.1 | 0.35 | 57.1 | 0.5 | 28.6 | 0.25 | |||
| 32 | 11/4″ | 42.2 | 3.56 | STD | 31.75 | 0.18 | 47.6 | 0.28 | 25.4 | 0.14 |
| 4.85 | X.S | 31.75 | 0.24 | 47.6 | 0.39 | 25.4 | 0.2 | |||
| 25 | 1″ | 33.4 | 3.38 | STD | 25.4 | 0.11 | 38.1 | 0.15 | 22.2 | 09 |
| 4.55 | X.S | 25.4 | 0.14 | 38.1 | 0.19 | 22.2 | 0.11 | |||
| 20 | 3/4″ | 26.7 | 2.87 | STD | – | – | 28.6 | 08 | 11.1 | 04 |
| 3.91 | X.S | – | – | 28.6 | 0.11 | 11.1 | 05 | |||
| 15 | 1/2″ | 21.3 | 2.78 | STD | – | – | 38.1 | 08 | 15.9 | 04 |
| 3.73 | X.S | – | – | 38.1 | 0.10 | 15.9 | 05 | |||
ASTM A234 Alloy Steel Buttweld Fittings Dimensions
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | ALL FITTINGS | ELBOWS AND TEES | 180 DEG RETURN BENDS | 180 DEG RETURN BENDS | 180 DEG RETURN BENDS | REDUCERS | CAPS |
|---|---|---|---|---|---|---|---|---|---|
| NPS | O.D. at Bevel (1), (2) | I.D. at End (1), (3), (4) |
Wall Thickness (3) | Centre-to-End Dimension A,B,C,M | Centre-to-Centre O | Back-to-Face K | Alignment of Ends U | Overall Length H | Overall Length E |
| ½ to 2½ | 0.06 -0.03 |
0.03 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 3 to 3 ½ | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 4 | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 5 to 8 | 0.09 -0.06 |
0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
| 10 to 18 | 0.16 -0.12 |
0.12 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 20 to 24 | 0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 26 to 30 | 0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.12 | … | … | … | 0.19 | 0.38 |
| 32 to 48 | 0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.19 | … | … | … | 0.19 | 0.38 |
ASTM A182 Alloy Steel Forged Fittings Dimensions
| Size | OD | WT | SR 90 Deg Elbows Centre – Face A | Weight | LR 90 Deg Elbows Centre – Face A | Weight | SR 45 Deg Elbows Centre – Face B | Weight | ||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch. | mm | mm | SCH | mm | kg | mm | kg | mm | kg |
| 500 | 20″ | 508 | 9.52 | STD | 508 | 93.5 | 762 | 140 | 318 | 85 |
| 12.7 | X.S | 508 | 124 | 762 | 186 | 318 | 112.5 | |||
| 450 | 18″ | 457 | 9.52 | STD | 457 | 75.6 | 686 | 113 | 286 | 56.5 |
| 12.7 | X.S | 457 | 100 | 686 | 150 | 286 | 75 | |||
| 400 | 16″ | 406.4 | 9.52 | STD | 406 | 59.5 | 610 | 89.3 | 254 | 45 |
| 12.7 | X.S | 406 | 78.7 | 610 | 118 | 254 | 59 | |||
| 350 | 14″ | 355.6 | 9.52 | STD | 356 | 45.4 | 533 | 68.1 | 222 | 34.1 |
| 12.7 | X.S | 356 | 60 | 533 | 90 | 222 | 45 | |||
| 300 | 12″ | 323.9 | 9.52 | STD | 305 | 35.4 | 457 | 53.1 | 190 | 26.6 |
| 12.7 | X.S | 305 | 46.7 | 457 | 70 | 190 | 35 | |||
| 250 | 10″ | 273.9 | 9.27 | STD | 254 | 24.1 | 381 | 36.1 | 159 | 18.1 |
| 12.7 | X.S | 254 | 32.5 | 381 | 48.8 | 159 | 24.4 | |||
| 200 | 8″ | 219.1 | 8.18 | STD | 203 | 13.6 | 305 | 20.4 | 127 | 10.2 |
| 12.7 | X.S | 203 | 20.9 | 305 | 30.9 | 127 | 15.5 | |||
| 150 | 6″ | 168.3 | 7.11 | STD | 152.4 | 6.8 | 229 | 10.1 | 95.2 | 5.1 |
| 10.97 | X.S | 152.4 | 10.2 | 229 | 15.3 | 95.2 | 7.7 | |||
| 125 | 5″ | 141.3 | 6.65 | STD | 127 | 4.8 | 190 | 6.8 | 79.4 | 3.4 |
| 9.5 | X.S | 127 | 6.5 | 190 | 10 | 79.4 | 5 | |||
| 100 | 4″ | 114.3 | 62 | STD | 101.6 | 2.8 | 152.4 | 4.2 | 63.5 | 2.1 |
| 8.56 | X.S | 101.6 | 3.9 | 152.4 | 5.7 | 63.5 | 2.9 | |||
| 80 | 3″ | 88.9 | 5.49 | STD | 76.2 | 1.45 | 114.3 | 2.18 | 50.8 | 1.1 |
| 7.62 | X.S | 76.2 | 1.95 | 114.3 | 2.86 | 50.8 | 1.45 | |||
| 65 | 21/2″ | 73 | 5.16 | STD | 63.5 | 0.95 | 95.2 | 1.46 | 44.4 | 0.73 |
| 71 | X.S | 63.5 | 1.27 | 95.2 | 1.82 | 44.4 | 0.91 | |||
| 50 | 2″ | 60.3 | 3.91 | STD | 50.8 | 0.5 | 76.2 | 0.72 | 34.9 | 0.36 |
| 5.54 | X.S | 50.8 | 0.68 | 76.2 | 1 | 34.9 | 0.5 | |||
| 40 | 11/2″ | 48.3 | 3.68 | STD | 38.1 | 0.26 | 57.1 | 0.4 | 28.6 | 0.2 |
| 58 | X.S | 38.1 | 0.35 | 57.1 | 0.5 | 28.6 | 0.25 | |||
| 32 | 11/4″ | 42.2 | 3.56 | STD | 31.75 | 0.18 | 47.6 | 0.28 | 25.4 | 0.14 |
| 4.85 | X.S | 31.75 | 0.24 | 47.6 | 0.39 | 25.4 | 0.2 | |||
| 25 | 1″ | 33.4 | 3.38 | STD | 25.4 | 0.11 | 38.1 | 0.15 | 22.2 | 09 |
| 4.55 | X.S | 25.4 | 0.14 | 38.1 | 0.19 | 22.2 | 0.11 | |||
| 20 | 3/4″ | 26.7 | 2.87 | STD | – | – | 28.6 | 08 | 11.1 | 04 |
| 3.91 | X.S | – | – | 28.6 | 0.11 | 11.1 | 05 | |||
| 15 | 1/2″ | 21.3 | 2.78 | STD | – | – | 38.1 | 08 | 15.9 | 04 |
| 3.73 | X.S | – | – | 38.1 | 0.10 | 15.9 | 05 | |||
Major Industrial Alloy Steel Fittings & Flanges Export Countries
United Arab Emirates (UAE), Jordan, Bahrain, Kuwait, Oman, Qatar, Saudi Arabia, United States of America (USA), Singapore, Malaysia, Azerbaijan, Armenia, Georgia, Egypt, Algeria, Nigeria, South Africa, Kenya, Morocco, Ethiopia, Ghana, Tanzania, Sudan, Uganda, Angola.
